NextPCB has been a specialist in PCB Prototype and PCB Manufacturing for 15 years. In order to offer the best service and competitive price to our customers, we dedicate a PCB prototype engineer and a PCB manufacturing engineer dedicated to each PCB fabrication. We also hold IATF, ISO, UL, RoHS, and REACH certifications ensuring the PCB quality. Our capabilities include:

• PCBs up to 32 layers
• Min.Trace/Space 3.5mil(3.5mil)
• Choose from Fr-4, Arlon, Polyamide substrate materials
• Quantities from 1-1000+
• PCB Dimensions up to 500*600mm
• Board Thicknesses from 0.6mm - 2.5mm
• Dimensional Tolerance of ±0.2mm
• Min. hole size of 0.2mm
• Outer Copper Weights of 35um/70um/105um
• Inner Copper Weight 0.5oz/1oz/2oz/3oz/4oz

PCB Assembly

NextPCB offers quick turnkey PCB assembly service, which can meet your needs from prototype quantities as well as small-volume to big-volume production. We deal with the whole process including: Sourcing all the components, PCB manufacturing, PCB assembly, testing, and final shipment. We have our own PCB Assembly manufacturer with 27 production lines to provide professional PCBA service and competitive price for our customers.

• Surface mount assembly (SMT)
• Ball-Grid-Array (BGA) Assembly
• Mixed technology (SMT & Thru-hole)
• Through-Hole Assembly
• Mixed Assembly
• Reflow Soldering
• Wave Soldering
• Pick & Place Assembly
• SMT Solder Paste Printing

Components Sourcing

We are capable of sourcing any required components in order to offer our customers a comprehensive PCB Assembly service. As we have been providing circuit assembly service for more than 15 years, NextPCB has already established cooperation with a number of world-famous component distributors including Digi-Key, Mouser Electronics, Arrow Electronics, Avnet, etc. this makes it possible for you to get high-quality components at low price.

Component Sourcing Types:

• Full Turnkey - NextPCB helps you source all the parts
• Partial Turnkey - Send some parts directly to NextPCB assembly facilities
• Kitted/Consigned

SMT Parts Presentation:

• Cut tape
• Partial reel
• Reel
• Tube
• Tray
• Laser-cut stainless steel

Component Types:

• BGA 0.25mm pitch
• Passive components as small as 01005 (0402) package
• Fine-pitch components as small as 0.38mm pitch
• Cable & Wire
• Bulk

Functional Testing (FCT)

NextPCB uses multiple methods to test the circuit board projects as the final step of assembly services. We do our best to make sure that you can get what you pay for!

• Automated Optical Inspection(AOI)
• In-Circuit Testing (ICT)
• Functional Testing(FCT)
• X-Ray testing
• Multiple stages of Visual Inspection

IC Programming

NextPCB could offer quick turnaround IC programming services, which will transfer a computer program into an integrated computer circuit.

We support lots of different package types (DIP, SDIP, SOP, MSOP, QSOP, SSOP, TSOP, TSSOP, PLCC, QFP, QFN, MLP, MLF, BGA, CSP, SOT and so on.). You can contact with your sales representative or support@nextpcb.com to help you.

We appreciate it a lot that the Intellectual Property(IP) contains the hard-working and wisdom of PCB engineers, so we prepare a Non-Disclosure Agreement (NDA) document to sign for each business cooperation. We also have a qualified programming management system.
